Maximus LED 5" / 6" recessed lighting downlight 20watt white reflector trim warm white 2700K dimmable

# DLS24-06C27D1E-WH-F1
Maximus 5" / 6" LED recessed lighting downlight reflector white reflector and white trim, 20watts, warm white 2700k rated at 35,000 hours replaces 90watt incandescent bulbs. Works with all of our 5" and 6" recessed housings including our LED specific Title 24 housing. Works in most 6" recessed cans. See our web page for housings that are hard to fit.

Designer's Note

One of the main reasons with like this is that is a very powerful LED light source but diffused. We find this is a great affordable LED Module for a number of applications. Use it where you need a lot of light, like in your kitchen, large walk in closet or office. You get the idea. The Module does have a very wide beam spread of about 110 degrees so it will spread out the light. In a word, it is bright 1200 Lumens, one of our brightest. At 27K it is a warm color temperature, good for a home where you do not want an ultra white light source to ruin the mood or make your rooms like like an airport waiting area. The LED Module fits all kinds of both 5"and 6" recessed cans. It does require torsion bar clips for cans that do not have them. We have a video on how to put them in and they are included in the box. Make sure you are aware of the process and have seen our video on hard to fit recessed cans, old and unusal recessed cans. We offer a video and a web page for your reference. Check back often as your project progresses. We have a very limited number of these and we always suggest on large projects to order a spare for the future as LED lighting changes every year and if you have a problem want to have a sparer on hand that will match.

Availability: Discontinued Item

$9.20

Here to Help

Quality lighting can increase sales, security and property value. Contact us here and we will show you how. Your success is our success.
Also enjoy our video guides and how to's here
Details
  • Insulated Ceiling (IC) housings
  • Airtight (AT) housings
  • Non-IC housings
Product Features & Benefits:
  • Torsion spring clips included with this product.
  • 1200 lumens - Replacement for halogen 90watt but more difused.
  • CRI of 90 for amazing color rendering!
  • Dimmable 10% to 100% works with most dimmers
  • 35,000 hour life
  • Suitable for indoor and damp locations, may be way to bright for a shower however.
  • CA65 Certified
  • CA24 Certified
  • 120V input voltage
  • No warm-up time, instant-on with full light output and stable lamp to lamp color
  • Meets California Title 24 fixture requirements for high efficacy luminaire
  • Integrated white trim and medium base socket adaptor (included) for direct replacement
Important Notes
  • Suitable for dimmers or in housings controlled by a dimmer.
  • Not intended for use with emergency light fixtures or exit lights.
  • Not suitable where fixture is enclosed.
  • For use in housings that can structurally support a lamp weighing one pound. (actual weight is 11oz)
  • Designed to install in standard 5" or 6" insulated and non-insulated housings.
Additional Information
Warranty 90 Days
Bulb Wattage 20
Voltage Type Line Voltage (120Volt)
ESR-4417 Yes
Average Hours 35,000
Attachment Type Torsion Spring
Lighting Application General Lighting, Task Lighting, Wall Wash Lighting, Accent Lighting
Application Kitchen Lighting, Area Lighting, LED Lighting, Office Lighting, Shower Lighting, Under eave lighting,
Compatible Housings TLS6-AT, TLS6IC-AT-W, TLS6R-AT, TLS6RIC-AT-W
Bulb Included Yes
Dimmable Yes
Material Aluminum, Plastic
Approvals California Title 24, FCC, UL, UL Listed for Damp Location
UPC 840623110980
Inside Color White
Outside Color White
Beam Spread Flood
Lumens 1200
Bulb Emit Color Warm White
Color Temperature ( K ) 2700
Color Render Index (CRI) 90
Incandescent Equivalent Wattage 90
Diameter (in) 7.48"
Height (in.) 3.52"
